eSSL X990 Access Control System

Product Description

STORAGE CAPACITY

• Fingerprint Capacity : 10000
• Card Capacity : 10000
• Transaction Capacity : 100000
• Card Reader : Inbuilt proximity card reader (Optional MI fare, HID prox)
• CPU : 32bit microprocessor
• SDRAM : 128 MB Nand Flash
• Flash : 256 MB Nand Flash
• Kernel : 2.6

BIOMETRIC

• Fingerprint sensor : 500 DPI Optical sensor
• FAR : <=0.0001%
• FRR : <=1%
• Identification speed : <0.5 sec
• Algorithm Ver : 10

AUDIO/VISUAL

• Display : 3" Color TFT
• Keypad : Yes
• LED Indicator : Green/Red
• Schedule Bell/Speaker : Mini Speaker

COMMUNICATION

• TCP/IP, USB, (Optional : WiFi, GPRS)
• Push data : Yes (support both static IP and domain server) Standard Features : work code,SMS,DLST, Self service query, Status Switch

POWER & ENVIRONMENT

• Power Supply : DC 12V --- 1.5Amp
• Operating Temperature : 0oC - 45oC
• Operating Humidity : 20% - 80%
• Dimension(in mm) : (L)210 x (W)157 x (H)40

ACCESS CONTROL

• Wiegand : In & Out both 26 or 34 bit (With or without site code)
• Relay : 12 V relay for lock EM lock, Bolt Lock or Strike lock
• Support Fire Alarm : Yes
• Door Sensor : Yes
• Anti Passback : Yes
• Door Bell : Yes

EXIT READERS

• Support exit readers : 101 HE , FR 1200, Push Button, KR500, Notouch, KR503

OPTIONAL

• Battery : Yes
• Card readers : Mifare/HID Prox
• Communication : WiFi/GPRS
• Sensor : Mifare/HID Prox

COMPATIBILITY

• Compatible with Multi Door controllers via weigand
• External Speaker output available (Optional)
• External Bulb output available (Optional)
• Support External Printer

COMPATIBLE SOFTWARE AND SDK

• eTimeTrackLite desktop & web
• SDK for desktop applications
• Web based Device Management application using Push data. Helps developers & integrators
• Supports 3rd Party Payroll/HRMS/ERP and Other applications

MAJOR APPLICATIONS

• Time & Attendance , Canteen Management, School Attedance, Production Management, Gym &
